- Provisioning BYOC Infrastructure
Create a Cloud Environment
Public Preview
This feature is currently in Public Preview. Exercise caution before using this for provisioning production environments. If you encounter issues creating a Cloud Connection or Cloud Environment, please submit a ticket.
Note
This document assumes that you have already created a Cloud Connection allowing StreamNative to connect to your cloud account. If you have not yet done so, please create one, and then return to this page to continue setting up your Cloud Environment.
Overview
Cloud Environments set up your AWS, GCP, or Azure account with everything it needs to create and run Pulsar Clusters. You can create a Cloud Environment either through snctl, or StreamNative's terraform provider. Once you have created a Cloud Environment, you can create an Instance and Pulsar Cluster through the StreamNative Console
Create a Cloud Environment with snctl
To create a Cloud Environment using snctl, use snctl create cloudenvironment. Usage:
snctl create cloudenvironment CLOUD_ENVIRONMENT_NAME --cloud-connection-name CLOUD_CONNECTION_NAME --region REGION --network-id NETWORK_ID --network-cidr NETWORK_CIDR
| Flag | Description |
|---|---|
| --cloud-connection-name | The name of cloud connection name. |
| --region | The region of Cloud Environment. For Azure, it's the resource group name |
| -h, --help | Display help message for cloudenvironment |
| --network-cidr | The network cidr of Cloud Environment. Cannot be specified if network-id is specified. |
| --subnet-cidr | The subnet cidr of Cloud Environment. Only required for Azure environments when cidr is specified. |
| --network-id | The network id of Cloud Environment. Cannot be specified if cidr is specified. |
Examples
AWS:
snctl create cloudenvionment usw1-dev --cloud-connection-name share-aws -n orgname
GCP:
snctl create cloudenvironment usw1-dev --cloud-connection-name shared-gcp --region us-west1 -n orgname
Azure:
snctl create cloudenvionment usw1-dev --cloud-connection-name share-azure -n orgname
Create a Cloud Environment with terraform
To create a Cloud Environment with terraform:
- Prepare
main.tf - Run
terraform init - Run
terraform apply
Cloud Environment Schema
| Field | Type | Description |
|---|---|---|
| name, required | String | Name of the cloud environment |
| organization, required | String | The organization name |
| cloud_connection_name, read-only | String | Name of the cloud connection |
| id, read-only | String | The ID of this resource |
| network, read-only | List of Object | see 'network schema' below for nested schema |
| region, read-only | String | The cloud region in which this environment will be created |
| network schema, read-only | cidr (String), id (String) |
Examples
resource "streamnative_cloud_environment" "usw1_dev" {
organization = "orgname"
name = "usw1-dev"
cloud_connection_name = "shared_aws"
region = "us-west-1"
network {
cidr = "10.60.0.0/16"
}
}
Monitoring the Provisioning Process
Creating a Cloud Environment through Terraform does not immediately create the Cloud Environment, but rather kicks off a process that creates it. In order to monitor that process, you can use snctl.
snctl describe -n orgname cloudenvironment name-of-your-environment
Once snctl describe returns a status of True and a type of Ready your Cloud Environment has been provisioned, and you can create a Pulsar Cluster within it. This should take approximately 40 minutes.
If this command returns an error state, please reach out to the StreamNative support team.
Recommended default CIDR Values
If you are using a StreamNative-managed VPC as described in the documentation above, we recommend the following default CIDR values.
- AWS
- Default VPC CIDR: 10.60.0.0/16 (must between /16 and /28), but we suggest using /16 to /18, otherwise there will not be enough IP addresses.
- The subnet CIDR will be calculated by VPC CIDR.
- GCP
- Default VPC CIDR: 10.0.0.0/16
- Azure
- Default VPC CIDR: 10.70.0.0/16
- Default Subnet CIDR: 10.70.0.0/24
